Product Information
Description
AquaFlo/Gecko Wet End
Side discharge, 2"mbt suction/discharge, 48 frame wet end for XP2/XP2E pump. This wet end is used with a 1.5 HP, 48 frame, thru-bolt style motor. The motor used may be either a single or dual speed. The wet end may be rotated 90 degrees to change the discharge position. The complete wet end includes: the volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring and suction cover screws.
Motor and unions sold separately.
NOTE: 1 Silver, 1 Yellow dot on the shaft of the impeller.
Product Specifications:
Pump to Motor Foot Types
9
Motor Frame
48 Frame Thru-Bolt
Drain Plug Location
4,6,9 o`clock
Suction Auxillary Port
None
Suction Style
Center
Suction Connection (Physical Dimension)
3-1/16"od
Suction Connection Type
Male Buttress Thread (mbt)
Suction Pipe Size
2"
Discharge Auxilary Port
None
Discharge Style
Side
Discharge Connection (Physical Dimension)
3-1/16"od
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Pipe Size
2"
Horsepower
1.5hp
Manufacturer
AquaFlo/Gecko
Pump Model
Flo-Master XP2e
Manufacturer Impeller Number
91695150
Volute Fastening Type
8 Screws
Volute/Sealplate Number
92770705
Additional Info
| Category | Parts Spa Parts Spa Pump Parts |
| SKU | PST-34-402-1204 |
| MPN | 91041815-000 |
| Replaces | 1-05-0327, 1-PW15EX420, 310-1130SF, 310-1140SD, 310-1140SF, 5038-0, 5121-64, 600018, 632267, 806105061669, 91041609, 91041815, AF9104181500, AQF-101-9957, AQF91041609, WWP3101140SD |
| Manufacturer | Aqua-Flo |
| Weight | 3.78 lb |
