H2Flow FlowVis FV-C-15 Flow Meter and Check Valve, 1-1/2 in Slip
Flow reading and check valve in one CPVC body.
Genuine H2Flow FlowVis FV-C-15 combination flow meter and check valve, sized for 1-1/2 in Sch 40 slip-fit plumbing. Reads 10 to 90 GPM directly on a clear GPM scale (LPM and FPS marks optional), and the integrated flapper handles backflow prevention so you do not need a separate check valve in the run. NSF 50 Level 1 certified for commercial pool service, factory calibrated, and installs horizontal, vertical, or upside-down with no loss of accuracy.
| Manufacturer | H2Flow Controls |
|---|---|
| Product Line | FlowVis |
| Model | FV-C-15 |
| Pipe Size | 1-1/2 in |
| Connection | Slip (Sch 40 socket) |
| Flow Range | 10 to 90 GPM |
| Pressure Rating | 50 psi |
| Body Material | CPVC |
| Body Color | Black |
| Accuracy | Equal to or greater than 97.9 percent across the FlowVis model range |
| Certification | NSF 50 Level 1 (across eight FlowVis models) |
| Doubles As | Check valve (integrated flapper) |
| Install Orientations | Horizontal, vertical, or upside-down |
| Calibration | Not required, factory calibrated |
| PST SKU | PST-26-042-1002 |
Can I install this right next to an elbow or other fitting?
Yes. The FlowVis is engineered to maintain accuracy with no straight-pipe run requirement, unusual for a flow meter. Most competing meters need 5 to 10 pipe diameters of straight pipe upstream to get a reliable reading. This unit reads true even when installed inches from an elbow, tee, or valve.
Do I still need a separate check valve?
No. The FV-C-15 doubles as the system check valve via the integrated flapper. Eliminates a fitting, a glue joint, and a leak point. Pair it with your pump discharge to prevent siphon-back when the system is off.
Will this fit my schedule 40 plumbing?
Yes. The slip end glues directly into a 1-1/2 in Sch 40 PVC socket fitting or coupling. Use standard PVC primer and cement, no special prep for the CPVC body. Dry-fit first, the flow direction arrow on the body must match the actual pump flow. For 2 in plumbing, use the FV-C-2 slip or the 2 in / 2-1/2 in spigot model instead.
Additional Info
| Category | Pool Products Pool Accessories Pool Flow Meters |
| SKU | PST-26-042-1002 |
| MPN | FV-C-15 |
| Replaces | 68252, EMO-561-1001, FLVFV15 |
| Manufacturer | H2Flow |
| Weight | 2.02 lb |
